Blackmagic Teranex Mini Analog to SDI 12G

The Blackmagic Teranex Mini Analog to SDI 12G is a professional broadcast converter designed to transform analog video and audio signals into high-quality SDI signals for use with modern broadcast, live production, studio, post-production and video distribution equipment. It provides a practical way to connect legacy analog video sources to contemporary SDI-based workflows while supporting video standards from standard definition through Ultra HD.

The converter can accept composite, Y/C (S-Video) and component analog video, making it suitable for a wide range of equipment including Betacam SP decks, HDV cameras, VHS equipment, set-top boxes and gaming consoles. The converted signal can then be delivered through its dual 12G-SDI outputs, allowing integration with professional SDI monitors, switchers, routers, recorders and other production equipment.

Professional Analog to SDI Conversion

Modern production environments often use SDI for reliable video transport, while many existing cameras, decks and playback devices still provide analog outputs. The Blackmagic Teranex Mini Analog to SDI 12G bridges this gap by converting analog sources into SDI signals that can be incorporated into professional video systems.

It supports analog component SD/HD, Y/C and composite NTSC/PAL input formats. This flexibility makes it useful for studios, broadcasters, event production companies, educational institutions, churches, archives and video professionals who need to integrate older equipment with newer SDI infrastructure.

12G-SDI Support for Modern Video Workflows

One of the major advantages of the Teranex Mini Analog to SDI 12G is its support for SD, HD, 6G and 12G-SDI. This allows the converter to accommodate a broad range of professional video formats, including Ultra HD workflows up to 2160p60.

The unit features two 12G-SDI outputs, providing flexible connectivity for professional production environments. Multiple outputs can be useful when the converted signal needs to be connected to more than one piece of SDI equipment within a workflow.

Wide Range of Analog Inputs

The converter accepts several analog video formats:

• Composite video
• Y/C or S-Video
• Component SD video
• Component HD video
• NTSC
• PAL

This makes it particularly useful when working with different generations of video equipment.

Professional Audio Integration

The Blackmagic Teranex Mini Analog to SDI 12G also provides professional audio connectivity. It features two channels of balanced analog audio through XLR connectors, allowing audio from compatible professional equipment to be embedded into the SDI output.

It also supports four channels of balanced 110Ω AES/EBU digital audio through XLR connections. The right XLR connection can additionally be configured for timecode input, providing further flexibility for professional production applications.

Ideal for Broadcast and Live Production

The Blackmagic Teranex Mini Analog to SDI 12G is designed for applications where analog sources need to become part of a professional SDI infrastructure. It can be used in television studios, live events, production facilities, video archives, houses of worship, educational facilities and professional AV installations.

For example, an older analog camera or playback deck can be connected to the converter and its output integrated into an SDI switcher or recorder. This can help organizations continue using existing equipment while gradually modernizing their video infrastructure.

Easy Configuration and Software Updates

The converter provides configuration through mini switches, USB and Ethernet, while Blackmagic Design also provides software utilities for configuration and internal software updates. This gives installers and operators greater control when integrating the unit into different production environments.

For users who want additional convenience, the Teranex Mini platform can also be configured with an optional front-panel Smart Panel featuring an LCD display, rotary knob and settings buttons.

Reliable Professional Construction

The Teranex Mini Analog to SDI 12G is built for professional installation and continuous production environments. It operates from 100–240V AC and has a rated power consumption of approximately 16 watts. The operating temperature range is 0°C to 40°C, while storage temperature is specified from -20°C to 60°C.

Blackmagic Design specifies a three-year limited manufacturer’s warranty for the product, providing additional assurance for professional users.

Key Features of Blackmagic Teranex Mini Analog to SDI 12G

• Professional analog video to SDI converter
• Supports SD, HD, 6G and 12G-SDI
• Supports video up to 2160p60
• Two 12G-SDI video outputs
• Composite analog video input
• Y/C or S-Video input
• Component SD/HD input
• Supports NTSC and PAL sources
• Two channels of balanced analog audio
• Four channels of balanced AES/EBU digital audio
• XLR audio connectivity
• Timecode input capability
• USB and Ethernet configuration
• Software updates through USB and Ethernet
• Optional Smart Panel support
• 100–240V AC power
• Suitable for broadcast and professional AV applications
• Three-year limited manufacturer’s warranty

Applications

Broadcast Studios

Connect legacy analog video equipment to modern SDI production systems for broadcast and studio workflows.

Live Events

Convert analog sources for integration with SDI switchers, production equipment, monitors and recorders during live productions.

Video Archiving

The converter can help organizations integrate older analog playback equipment into modern digital production and recording environments.

Churches and Institutions

Suitable for churches, schools, universities and other organizations upgrading their AV systems while continuing to use existing analog equipment.

Professional Video Production

Video production companies can use the converter to connect analog cameras, decks and other sources to SDI-based workflows.

Why Choose the Blackmagic Teranex Mini Analog to SDI 12G?

The Blackmagic Teranex Mini Analog to SDI 12G provides a practical solution for connecting analog video equipment to modern professional SDI infrastructure. Its support for multiple analog formats, 12G-SDI output, professional audio connections and Ultra HD video standards makes it suitable for demanding video production environments.

For businesses and professionals looking to modernize an existing studio or production setup without immediately replacing every analog source, this converter provides an effective connection between older equipment and newer SDI technology.

If you are looking for a Blackmagic Analog to SDI converter in Kenya, the Teranex Mini Analog to SDI 12G is a professional option for broadcast, live production, AV integration and video conversion applications.

For availability and purchasing information, contact Neriahtech Computers on +254 113 81 81 82 or email neriahtechcomputers@gmail.com.

You can also explore Neriahtech Computers through Facebook and Instagram.

Product Specifications

Product Type: Blackmagic Teranex Mini Analog to SDI 12G
Conversion: Analog Video to SDI
SDI Support: SD, HD, 6G and 12G-SDI
Maximum Video Format: Up to 2160p60
SDI Outputs: 2 × 12G-SDI
Analog Video Inputs: Composite, Y/C and Component
Analog Audio: 2 channels balanced analog audio via XLR
Digital Audio: 4 channels balanced AES/EBU via XLR
Configuration: Mini Switches, USB and Ethernet
Power: 100–240V AC
Power Consumption: 16W
Operating Temperature: 0°C to 40°C
Warranty: 3-year limited manufacturer’s warranty
